GP-PWM-30-UL
_________________________________________________________________________________
30
© 2018 GoPower!
How to tell:
1. The State of Charge (SOC) screen is close to 100% and the Sun
and Battery icon are present with an arrow between.
2. With the solar array in sunlight, check the voltage at the
controller solar array terminals with a voltmeter.
3. If there is no reading at the controller solar array terminals, the
problem is somewhere in the wiring from the solar array to the
controller.
Remedy:
1. Hold down the MAX BOOST Button for approximately 3 seconds
to activate Maximum Power Boost. This will allow the controller
to charge batteries to 14.4 +/- 0.1 VDC (14.4 +/- 0.1 VDC
Sealed/Gel) with all current the solar array is producing.
2. Check all connections from the controller to the array including
checking for correct wire polarity. Check that all connections are
clean, tight, and secure. Continue with the solutions below for
additional help on low current readings.
Current Reading: Less than expected
Time of Day: Daytime, clear sunny skies
Possible Causes:
(1) Current is being limited below 1 Amp as per normal operation.
(2) Incorrect series/parallel configuration and/or wiring connections
and/or wire gauge.
(3) Dirty or shaded module or lack of sun.
(4) Blown diode in solar module when two or more modules are
connected in parallel.
(5) The battery is full.
How to tell:
(1) Battery State of Charge screen is close to 100% and the Sun and
Battery icon are present with an arrow in between.
