Go Power GP-PWM-30-UL User Manual

GP-PWM-30-UL
_________________________________________________________________________________
6
© 2018 GoPower!
Operating Consumption
(Display backlight on)
15mA
• RoHS Compliant,
environmentally safe
• Accepts up to 495
watts of solar at 12
volts
• Maximum Power
Boost Technology
Operating Consumption
(Display backlight off)
6mA
Battery Types Supported
Vented and Sealed (GEL, AGM etc.)
Lead Acid
Bulk/Absorption Voltage
(Sealed/Gel, AGM,
Flooded)
14.1/14.4/14.4V (25°C / 77°F),
30min / Day
or 2hr if battery voltage < 12.3V
Float Voltage
13.7V (25°C / 77°F)
Equalization Voltage
14.9V (25°C / 77°F),
2h / 28 Days
or if battery voltage < 12.1V
Temperature Compensation
- 24mV/ºC / 13mV/ºF
USB charger
5V, 800mA
Low Voltage Disconnect
(USB)
11.0 VDC
Reconnects once battery reaches
12.8V
Operating Temperature
Display Operating
Temperature
- 40 to 60°C / - 40 to 140°F
- 10 to 55°C / 14 to 131°F
Charge Current De-Rating
(Based on internal
temperature of the
controller)
Internal Temp.
Max Charge
Output Current
<80°C/176°F
37.5A
80°C/176°F
22.5A
81°C/177.8°F
15A
82°C/179.6°F
7.5A
>82°C/179.6°F
0A
Humidity
99% N.C.
Protection
Battery Reverse Polarity, Solar Array
Reverse Polarity, Over Temperature,
PV Short Circuit, Over Current
