45
6 Maintenance and Adjustment
6.1 Installing / removing the print head module
Open the printer
cover.
Turn the print head
counterclockwise
to a top right position
$
using a screwdriver or a
coin, loosen the screw to
take out the TPH module.
Hold the print head module
, pull out the TPH cable smoothly.
To install TPH module, follow the reverse order.
* Remember to switch off the printer before removing the print head module.
1RWH
