Godex RT730i User Manual

8
2 Printer Setup
008
Load the Ribbon on the Printer
For Ribbon Supply Module
RIBBON SUPPLY MECHANISM
RIBBON SUPPLY SPINDLE FIXED SLOT
RIBBON SUPPLY WHEEL
Place
RIBBON SUPPLY
MODULE
1. Place the ribbon module into the printing mechanism. Please the left-hand side of ribbon supply spindle
fixed slot first. Make sure the holder of square fixed shaft is inserted into the notch. Then place the
right-hand side of ribbon positioning round shaft. Can be fixed ribbon supply module.
放入
Left side
SQUARE FIXED SHAFT
RIBBON SUPPLY SPINDLE
FIXED SLOT
Place
Right side
POSITIONINGROUND SHAFT
Place
POSITIONING HOLES

Godex RT730i Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	762 mm
Maximum printing width	105.7 mm
Display	LCD
Product color	Black
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	8 MB
Certification	CE (EMC), FCC Class A, CB, CCC, cUL
Internal memory	16 MB
Built-in barcodes	1D, 2D, Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Windows code pages supported	1250, 1251, 1252, 1253, 1254, 1255, 1257
Ribbon width	110 mm
Core diameter	25.4 mm
Ribbon length	300 m
Media thickness	0.06 - 0.2 mm
Maximum roll diameter	127 mm
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 85 %
Power requirements	100-240V, 50-60Hz
Compatible operating systems	Windows 2000, XP, Vista, 7, Windows Server 2003, 2008

Weight and Dimensions

Depth	280 mm
Width	210 mm
Height	186 mm
Weight	3000 g
