Godex RT730i User Manual

33
3 Setting and Control for Operation Panel
030
Status of LCD Interface
When printer is on standby status (ready to print), the LCD interface will display “Ready” on screen.
You can only print on this “Ready“ status.
If there is any printers error, the LCD screen will display the error screen to show the type of error.
You can fix the error according the notice.
WARNING ICON
ERROR DESCRIPTION
ERROR ICON
Icon Definition
To upper level
Appears on the NAVIGATION ICON of Setting
Pages. It guides you back to upper level by
pressing “LEFT“ key.
To upper level
Appears on the NAVIGATION ICON of Setting
Value Pages. It guides you back to upper level
by pressing “UP“ key.
Lock
On Setting Value pages, press “RIGTH“ key to
lock the value for preventing unexpected
change.
Unlock
For locked value, press “RIGHT” key again to
unlock the value.
Scroll the value
On Setting Value pages, press “UP“ or “DOWN“
key to scroll the values for your selection.
Check Ribbon

Godex RT730i Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	762 mm
Maximum printing width	105.7 mm
Display	LCD
Product color	Black
Wi-Fi	No
Ethernet LAN	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	8 MB
Certification	CE (EMC), FCC Class A, CB, CCC, cUL
Internal memory	16 MB
Built-in barcodes	1D, 2D, Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Windows code pages supported	1250, 1251, 1252, 1253, 1254, 1255, 1257
Ribbon width	110 mm
Core diameter	25.4 mm
Ribbon length	300 m
Media thickness	0.06 - 0.2 mm
Maximum roll diameter	127 mm
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 85 %
Power requirements	100-240V, 50-60Hz
Compatible operating systems	Windows 2000, XP, Vista, 7, Windows Server 2003, 2008

Weight and Dimensions

Depth	280 mm
Width	210 mm
Height	186 mm
Weight	3000 g
