| FRONT PANEL
4
LED status light
1
IR reciver
2
Headphone output 6,3mm jack
3
8
1
LED status light:
Red = standby
Blue = ON
Green = powered by the external power
supply PSU-10 EVO
FRONT PANEL OVERVIEW
The front panel of the HP-10 has been
designed for ease of use and everyday
reliability. The intuitive touchscreen display,
coupled with the SKC (Single Knob Control),
allows you to quickly check settings at a
glance and adjust all parameters with ease.
Additionally, all four headphone outputs are
conveniently located on the front panel for
immediate and easy access.
Through the touchscreen display and the
SKC, all the functions of the HP-10 can be
adjusted on the go. The touchscreen display
features a clear and intuitive user interface,
designed to offer the best possible user
experience and immediate control.
5
3
6
7
Touchscreen display
4
Headphone output 3,6mm jack
7
SKC (Single Knob Control)
8
6
Headphone output 4,4mm jack
4-pin XLR
5
2
