WEIGHT
Base: includes frame, motors, wheels, seat receivers, and
shrouds
88 lbs.
Armrests with joystick 14 lbs.
Seat with headrest (without armrests) 34 lbs.
Batteries (each) U1 = 24 lbs.
NF22 = 39 lbs.
Total weight with batteries With U1batteries = 184 lbs.
With NF22 batteries = 214 lbs.
OVERALL DIMENSIONS
Length With standard footrest = 38 1/2 in.
With extended footrest = 41 1/2 in. to 43 in.
Width (measured from outsides of tires) 24 1/2 in.
MAXIMUMS
Incline 6°
Speed 5 mph
Load Capacity 300 lbs.
TURNING RADIUS Without footrest = 15 in.
With standard footrest = 19 in.
With extended footrest = 22 in.
WHEEL SIZES Drive wheels = 10 in. x 3 1/2 in.
Casters = 6 in. x 2 in.
SEAT DIMENSIONS
Standard seat cushion 18 in. x 18 in., 18 in. x 20 in., 20 in. x 20 in.
Adjustable armrest width (measured from outsides) 23 1/4 in. to 29 3/4 in.
Adjustable armrest-to-seat cushion height 8 in., 9 in., or 10 in.
Adjustable seat-to-floor height With U1 batteries = 18 in. to 23 in.
With NF22 batteries = 20 in. to 23 in.
Adjustable seat back-to-floor height with U1 batteries
(Add 2 in. to each measurement if using NF22 batteries.)
Without headrest = 37 in. to 41 in.
With headrest unextended = 45 in. to 49 in.
With headrest extended = 50 in. to 54 in.
Adjustable footrest-to-floor height 5 in., 5 5/8 in., 6 1/4 in., 6 7/8 in., or 7 1/2 in.
ADJUSTABLE FOOTREST ANGLE - 4° to 17°
CONTROLLERS Integral OR Dynamic Shark; 60 amp programmable with
K10 or K11 lockout
CHARGER Off board, 110 VAC 60 Hz 5 amp
COLORS Candy Apple Red, Artic Blue, Hunter Green, Onyx
BATTERIES (recommended) Two U1 (35 Ah) SLA, AGM, or Gel; OR two NF22 (55 Ah)
