5 Yellow indicator front drive engaged
6 Red warning light PTO disengaged
7 Yellow indicator lift filter clogged
8 Red indicator parking brake engaged
9 Red indicator roll bar lowered
10 Red warning light hydraulic fluid filter clogged
11 Green indicator turn signals
12 Green indicator trailer turn signals
13 Blue indicator high beams (not for on-road use)
14 Fuel gauge
15 Engine coolant temperature indicator
16 Hour counter/tachometer
17 Digital display
18 Low fuel warning light
19 High temperature warning light
See fig.12
1 Trailer power connection
2 Auxiliary spooling valve hook ups (optional)
3. MODEL IDENTIFICATION
Model, series and chassis number are the tractor identification data. They are
found on a special metal plate n.1 fig.18.
4. OPERATING INSTRUCTIONS
4.1 LIGHT SWITCH
See fig.3 (n.3 fig.1).
0 = Off.
1 = Parking lights.
2 = Low beams.
3 = High beams (not for on-road driving).
Push: horn.
4.2 ENGINE IGNITION SWITCH
See fig.4 (n.2 fig.1). Consult engine instruction booklet.
.
Before starting the engine, depress the forced reset pedal (n.10 fig.1) to close
the engine start enable switch and turn the key as follows:
0 = No circuit live.
P = Heat glow plugs. Hold in this position for 8-10 seconds
1 = Instruments and indicator lights on (running position).
2 = Engine ignition.
