4
*
A. Handset.
B. Function buttons, access and selection of menu
functions.
The function of each button is shown on the monitor
screen with an icon located just above each button
(see pp. 6 to 22).
Press to access 'Doctor mode' function (standby monitor):
- With the special code '0441' (Doctor mode) already
entered pp. 23 to 26 1(see ), press the button for sec. for
menu access & then to activate/ deactivate the function.
- The push button led will blink in white color and the
icon if thewill be displayed in the main menu
function 'Doctor mode' is activated and it will turn off if
the function is deactivated.
C. LED:Monitor status
Yellow ON: Standby without notification.
Red ON: “Do not disturb” Mode a tivated.c
D. Cable slot (ART 4TH LITE G2+ monitor).
E. Speaker (h communication mode).ands-free
F. 4.3" TFT colour screen.
G. Golmar use.
H. (h communication mode).ands-freeMicrophone
I. Communication with hearing aids (ART 4H LITE G2+/
ART 4TH LITE G2+). Set the hearing aid switch to the T
position, see page .2 to 3
J. Raised dots for the visually impaired people.
In call :/ communication
Above this raised dot is the 'Start/ nd communication'E
button.
Above these raised dots is the 'Door opening' button.
K. Configuration switches.
L. .Installation terminals
M. Wall mounting connector fixing (x4).
N. Speaker (ART 4TH LITE G2+ “communication with
handset”).
O. Microphone (ART 4TH LITE G2+ “communication with
handset”).
DESCRIPTION
G
A
F
B
C
I
J
G
H
E
D
M
K
L
M
N
SA
GND
HZ
HZ
ON
1 2 3 4 5 6 7
8
BUS
BUS
SA
OFF = 0
ON = 1
DIP 1 to 7
DIP 8
Monitor
address
EOL
resistor
GND
HZ
HZ
BUS
BUS
128
codes
A
D
O
ART /G2+4 MONITORLITE
