Important: Do not change the configuration jumper's factory position.
Description of the door panel illumination LEDs (for low light conditions):
The door panel lighting LEDs will turn on during a call if the door panel lighting
at that moment is low. This enables the user to view the person who has called
from the apartment monitor.
*
( )
*
( )
Factory setting.
Description of the visual signals on the door panel:
Visual signals on the door panel for people with impaired hearing, indicating:
- In call: LED ' ' will illuminate during in call and in communication times.
- In communication: LED ' ' will illuminate during the communication process.
- When the door is open: LED ' ' will illuminate when the door is open.
- When ending communication: LEDs ' ' and ' ' will turn off.
- With more than one door panel, when calling and one is already in communication: LED ' '
will illuminate for 3 seconds.
.
-
In call and the monitor is in 'Do not disturb' mode: LED ' ' will illuminate for 4 seconds.
- In call (apartment without monitor or telephone): LED ' ' will illuminate for 4 seconds.
Description of the vocal synthesis (audible signals on the door panel):
Audible signals on the door panel for people with impaired vision.
If vocal synthesis is enabled on the sound module (see page 6 and 8 for configuration), the following voice
messages can be heard on the door panel:
- In call: 'Call is in progress'.
- When the door is open: 'Door Opened!'.
- When ending communication: 'Communication is finished'.
- With more than one door panel, when calling and one is already in communication: 'System is busy, try later'.
- While calling and the monitor is in 'Do not disturb' mode: 'Call is in progress'.
- In call (apartment without monitor or telephone): 'Resident Unavailable'.
