Goobay MS-506PQ-N User Manual

8
Switching commands 13 V,18 V,13 V / 22 KHz, 18 V / 22 KHz
Switching voltages 15 ±0.5 V 15 ±1 V
LNB Power supply Max 600 mA Max 1000 mA
Power supply (switchable) 230 V AC/50 Hz or 24 V DC
Article 67264 67265 67266 67267 67268
Frequency 47-2150 MHz
Inputs 8 SAT + 1 TERR
Outputs 4 6 8 12 16
Insertion loss
Terr 47-862MHz -1 dB -1 dB 0 dB -2 dB -1 dB
Sat 47-2150MHz -1 dB -1 dB 0 dB 2 dB -5 dB
Linearity
Terr 47-862MHz ±2 dB
Sat 47-2150MHz ±2 dB
Isolation
Terr / Sat 30 dB 30 dB 25 dB 30 dB 30 dB
Sat / Terr 30 dB
Kreuzpolarität H/V (Sat)
Out - Out
Terr 47-62MHz 26 dB 26 dB 26 dB 28 dB 26 dB
Sat 47-150MHz 28 dB 28 dB 28 dB 30 dB 28 dB
Return loss
Terr Input 47-862MHz 12 dB 11 dB 11 dB 12 dB 12 dB
Terr Output 47-862MHz 8 dB 8 dB 8 dB 10 dB 10 dB
Sat Input 950-2150MHz 14 dB 14 dB 14 dB 10 dB 10 dB
Sat Output 950-2150MHz 8 dB 8 dB 7 dB 10 dB 10 dB
Output level
Sat EN 50083-3 100 dBμV
Terr EN 50083-5 84 dBμV 84 dBμV 84 dBμV 83 dBμV 83 dBμV
Switching commands 13 V,18 V,13 V / 22 KHz, 18 V / 22 KHz, DisEq 2.0
Switching voltages 15 ±0.5 V 15 ±1 V 15 ±1 V 15 ±1 V 15 ±1 V
LNB Power supply Max 600 mA Max 1000 mA Max 1000 mA Max 1000 mA Max 1000 mA
Power supply (switchable) 230 V AC/50 Hz or 24 V DC
9 EC Declaration
With the CE sign the Goobay
®
, a registered trademark of the Wentronic GmbH ensures, that the product is conformed to
the basic national and european standards and directives. All trademarks and registered brands are the property of their
respective owners.
10 Contact
Goobay
®
Pillmannstraße 12
38112 Braunschweig
Germany
Made in China.
Hotline: +49 (0180) 5005882
E-Mail: info@goobay.de
Web: www.goobay.de
*(0.14 € per minute from German landline.
Maximum 0.42 € per minute from mobile networks.)
11 Document
Revision date: 2013-04-24
Version 3
EN
USER‘S MANUAL FOR SAT MULTISWITCHES
MS-506PQ-N/508PQ-N/512PQ-N/516PQ-N AND
MS-904PQ-N/906PQ-N/908PQ-N/912PQ-N/916PQ-N
