Rudder stocks are uniquely port and starboard. When first attaching rudders they will be stiff, you
can lubricate the transom pintles with a small amount of grease to assist you in this process.
Place the stocks onto the pintles at the transom. Make sure the lock plates snap over the casting and
if safety requirements require it, fit the retaining rings on the bottom pins as well.
The cross bar has easy connectors for a quick assembly. Make sure the easy connector for the tiller
extension is facing upwards / forwards.
You should check you rudder alignment before sailing for the first time, see the Tuning section on
how to do this.
For the safety of yourself and others please ensure you are familiar with the Lock down mechanism
before venturing onto the water.
