3 Hardware Overview
3.1 Hardware Layout
The top view and the bottom view of a GR5515 SK Board are shown in Figure 3-1 and Figure 3-2 respectively. The
board mainly integrates an interface microcontroller unit (MCU), a power module, Arduino Uno Shield Connectors,
buttons and LEDs, a LCD connector, a Bluetooth LE RF module, and an on-board QSPI flash.
Power module Interface MCU
Buttons and LEDs
Bluetooth LE RF
module
Arduino Uno Shield Connectors Arduino Uno Shield Connectors
LCD connector
Figure 3-1 Hardware layout of GR5515 SK Board (top view)
