SPECIFICATIONS
10
NOTE: The noise data is based on hemi-anechoic chamber, during actual operation. Because of ambient conditions, these values may be
somewhat different than shown.
Specifications are subject to change without prior notice.
MSG-24*
)
MSG-24CRN1 MSG-24HRN1
Power Supply - Ph/V/Hz
1, 208/230V/60Hz 1, 208/230V/60Hz
Cooling
Capacity, Btu/H 24,000 24,000
Input, watts 2,000 2,000
Rated current - amps 8.8 8.8
SEER - Btu/w.h 13.0 13.0
Heating
Capacity, Btu/h --- 24,000
Input, watts --- 2,000
Rated Current - amps --- 8.8
HSPF - W/W --- 7.7
Max. Current - amps 14 14
Starting Current - amps
34.8 34.8
Compressor
Model PA200X2CS-3MKUU PA200X2CS-3MKUU
Type Rotary Rotary
Brand Toshiba Toshiba
Capacity - Btu/h
19820 / 20130 +
5% 19820 / 20130 + 5%
Input, watts
2000 / 1980 +
5% 2000 / 1980 + 5%
Rated current (RLA) - amps
9.70 / 8.75 +
5% 9.70 / 8.75 + 5%
Locked rotor (LRA) - amps 34.8 34.8
Thermal protector UP3SE0396-T39 UP3SE0396-T39
Capacitor -
μ
F50
μ
f / 450V 50
μ
f / 450V
Refrigerant oil - oz. / ml 25 oz. / 750 ml 25 oz. / 750 ml
Indoor Fan Motor
Model YDK50-4B YDK50-4B
Brand Welling Welling
Input, watts 82 / 69 / 58 82 / 69 / 58
Capacitor -
μ
F
33
Speed RPM/minute (High, Med, Low) 1,260 / 1,100 / 990 1,260 / 1,100 / 990
Indoor air flow - CFM (High, Med, Low)
677 / 600 / 581 677 / 600 / 581
Indoor air flow - (High, Med, Low) / m3/h 1150 / 1020 / 930 1150 / 1020 / 930
Indoor noise level - dB(A) (High, Med, Low)
47 / 44 / 42 47 / 44 / 42
Outdoor Fan Motor
Model YDK100-6EB YDK100-6EB
Brand Welling Welling
Input, watts 160 160
Capacitor -
μ
F4
μ
f / 450V 4
μ
f / 450V
Speed RPM/Minute 740 740
Outdoor air flow - CFM
1,471 1,471
Outdoor air flow - m
3
/h
2,500 2,500
Outdoor noise level - dB(A) 59 59
Refrigerant type R410A - Oz. / g
85 oz. / 2400 g 86 oz. / 2450 g
Design pressure - PSI / 'MPa 653 / 4.5 653 / 4.5
Refrigerant Piping
Liquid side / gas side (Inches / mm)
3/8" / 5/8" -
Φ
9.53 /
Φ
16 3/8" / 5/8" -
Φ
9.53 /
Φ
16
Max. refrigerant pipe length (feet / m) 33' / 10 m 33' / 10 m
Max. difference in level (feet / m) 16' / 5 m 16' / 5 m
Operation temp. - (°F) / (°C) 63°F - 86°F / 17°C - 30°C 63°F - 86°F / 17°C - 30°C
Ambient temp. - (°F) / (°C)
64°F - 113°F / 18°C - 45°C 19°F - 113°F / -7°C - 45°C
Approximate Application area - Sq. ft. / m
2
431 - 603 / 40 - 56 431 - 603 / 40 - 56
