SPECIFICATIONS
8
NOTE: The noise data is based on hemi-anechoic chamber, during actual operation. Because of ambient conditions, these values may be
somewhat different than shown.
Specifications are subject to change without prior notice.
MSG-12*
MSG-12CRN1 MSG-12HRN1
Power Supply - Ph/V/Hz
1, 208/230V/60Hz 1, 208/230V/60Hz
Cooling
Capacity, Btu/H 12,000 12,000
Input, watts 1,050 1,050
Rated current - amps 4.6 4.6
SEER - Btu/w.h 13.0 13.0
Heating
Capacity, Btu/h 13,000 13,000
Input, watts 1,050 1,050
Rated Current - amps 4.6 4.6
HSPF - W/W 7.7 7.7
Max. Current - amps
7.6 7.6
Starting Current - amps
21 / 23.5 21 / 23.5
Compressor
Model PA108X1C-3FZDU PA108X1C-3FZDU
Type Rotary Rotary
Brand Toshiba Toshiba
Capacity - Btu/h 10,850 / 1,100 10,850 / 1,100
Input, watts 1,070 / 1,075 1,070 / 1,075
Rated current (RLA) - amps 5.2 / 4.8 5.2 / 4.8
Locked rotor (LRA) - amps 21 / 23.5 21 / 23.5
Thermal protector B185-135-141E B185-135-141E
Capacitor -
μ
F35
μ
f / 450 VAC 35
μ
f / 450 VAC
Refrigerant oil - oz. / ml 12 oz. / 350 ml 12 oz. / 350 ml
Indoor Fan Motor
Model WZDK25-38D WZDK25-38D
Brand Welling Welling
Input, watts 32 32
Capacitor -
μ
F
---- ----
Speed RPM/minute (High, Med, Low) 1,270 / 1,100 / 1,000 1,270 / 1,100 / 1,000
Indoor air flow - CFM (High, Med, Low)
441 / 365 / 325 441 / 365 / 325
Indoor air flow - (High, Med, Low) / m3/h 750 / 620 / 550 750 / 620 / 550
Indoor noise level - dB(A) (High, Med, Low)
45 / 41 / 38 45 / 41 / 38
Outdoor Fan Motor
Model YDK36-6B YDK36-6B
Brand Welling Welling
Input, watts 85 85
Capacitor - μF2.5μF/450V 2.5μF/450V
Speed RPM/Minute 930 930
Outdoor air flow - CFM
1,118 1,118
Outdoor air flow - m
3
/h
1,900 1,900
Outdoor noise level - dB(A)
55 55
Refrigerant type R410A - Oz. / g 48 oz. / 1350 g 48 oz. / 1350 g
Design pressure - PSI / 'MPa
653 / 4.5 653 / 4.5
Refrigerant Piping
Liquid side / gas side (Inches / mm)
1/4" / 1/2" -
Φ
6.35 /
Φ
12.7 1/4" / 1/2" -
Φ
6.35 /
Φ
12.7
Max. refrigerant pipe length (feet / m) 33' / 10 m 33' / 10 m
Max. difference in level (feet / m) 16' / 5 m 16' / 5 m
Operation temp. - (°F) / (°C)
63°F - 86°F / 17°C - 30°C 63°F - 86°F / 17°C - 30°C
Ambient temp. - (°F) / (°C)
19°F - 113°F / -7°C - 45°C 19°F - 113°F / -7°C - 45°C
Approximate Application area - Sq. ft. / m
2
194 - 280 / 18 -- 26 194 - 280 / 18 -- 26
