06
Avoidthewaterpipesandcablesburiedinthewallwhendrillingholes.
NOTICE
ThePVboxshouldbeinstalledwhenGW15KAU-DTorGW20KAU-DTisusedinAustraliaonly.
InstallthecoverofthePVboxafterconnectingtheDCinputcabletotheequipment.Otherwise,
theDCinputcablecannotbeconnected.
1 2
3
6
5
M5
1.2~2N·m
4
M5
1.2~2N·m
7
8
9
Installing the Inverter
