Goodwe GW10KAU-DT Quick Installation Guide

07
L=L1+(1~2)mm
L1
M5
1.2~2N·m
1
2 3
Devalan DC Connector
1
7~8mm
7~8mm
2
3
2.5mm ≤S≤4mm
4~5mm
1
1
2
2
1
1
2
2
04 Electrical Connection
Connecting the PE Cable
Connecting the DC Cable
NOTICE
ThePVboxisdesignedforGW15KAU-DTorGW20KAU-DTinAustraliaonly.Installthecoverof
thePVboxafterconnectingtheDCinputcabletotheequipment.
