Goodwe GW8KAU-DT User Manual

12
03 Product Introduction User Manual V1.0-2022-01-17
Inverters Designed without LCD
Indicator Status Description
ON = EQUIPMENT POWER ON
OFF = EQUIPMENT POWER OFF
ON = THE INVERTER IS FEEDING POWER
OFF = THE INVERTER IS NOT FEEDING POWER
SINGLE SLOW FLASH = SELF CHECK BEFORE CONNECTING TO
THE GRID
SINGLE FLASH = CONNECTING TO THE GRID
ON = WIRELESS IS CONNECTED/ACTIVE
BLINK 1 = WIRELESS SYSTEM IS RESETTING
BLINK 2 = WIRELESS ROUTER PROBLEM
BLINK 4 = WIRELESS SERVER PROBLEM
BLINK = RS485 IS CONNECTED
OFF = WIRELESS IS NOT ACTIVE
ON = A FAULT HAS OCCURRED
OFF = NO FAULT

Goodwe GW8KAU-DT Specifications

General

Number of MPPT	2
THDi	<3%
AC Grid Frequency	50/60Hz
Grid Frequency Range	45-55Hz / 55-65Hz
Peak Efficiency	98.3%
Protection Degree	IP65
Rated Power	8000W
Max. DC Power	12000W
Max. DC Input Power	12000W
Rated AC Power	8000W
Rated AC Voltage	230V
AC Voltage Range	180-280 V
Power Factor	0.8 leading to 0.8 lagging
Operating Temperature Range	-25°C to 60°C
