GORAVE AR5 AUDIO RECEIVER
Owner’s Installation and Operation Manual
V1.4 / 12-16-2014
10
stereo RCA cable. When connected, use the controls on the auxiliary device to control volume and operating
functions.
3.10 Reset / Clear All Settings
To clear all saved Audio Senders from the Favorites List, press the Connect button six times. The LED status
indicator will ash red, the AR5’s Favorites List will be cleared and volume settings reset. This lets you add new
Audio Senders to the Favorites List.
3.11 Additional notes
a) A GoRave AR5 can save up to ten (10) GoRave Audio Senders in its Favorites List.
b) The AR5 will auto-add an Audio Sender to its Favorites List if you play from it for 30 minutes.
c) The GoRave volume control app identies the available AR5 Audio Receivers your device can play to (via
its Audio Sender). Go to the App Store and search “GoRave” to download the app.
4. Loudspeakers
4.1 Speaker Selection
Connect GoRave loudspeakers to your GoRave AR5 Audio Receiver. GoRave components are tuned to work
together and deliver the best possible audio experience.
Use a speaker with a minimum impedance of 4 ohms. Driving two 4 Ω speakers from a single channel in paral-
lel or bridged conguration is possible.
4.2 Speaker Wire Selection
Use insulated two-conductor stranded wire to connect your GoRave AR5 to your GoRave loudspeakers. The
size and quality of the wire can have an audible effect on the performance of the system. Based on resistance
(Ohms) per foot on stranded cable, the table below provides a distance guideline to ensure your cable is sized
to deliver the best audio experience. Ensure the cable you select meets local building codes.
Wire Gauge Distance (8 ohm speaker
impedance)
Distance (6 ohm speaker
impedance)
Distance (4 ohm speaker
impedance)
18 AWG 60' / 18.2m 45' / 13.6m 30' / 9.1m
16 AWG 100' / 30.4m 75' / 22.8m 50' / 15.2m
14 AWG 150' / 45.7m 110' / 33.5m 75' / 22.8m
12 AWG 250' / 76.2m 180' / 54.8m 125' / 38.1m
10 AWG 400' / 122m 300' / 91.4m 200' / 61m
