Grace NP-P01 - Page 9

9
Model NP-PA
Dimension (WxHxD) MM 665x787x610
Weight KG 120
Air inlet Pipe MM 76
Air outlet Pipe MM 76
Heat Area M2 140
Automatic Burning Time (Min-Max.) H 13/33
Fuel Wood Pellet
Consumption for Pellet (Min-Max) 0.8/2.1
Efficiency % 83%
Hopper Capacity KG 27
Electronic consumption W/H 100-400
Rating Voltage and Frequency V/HZ 230/50-115/60
Rating Power KW 13
Model NP-PA-01
Dimension (WxHxD) MM 490x680x450
Weight KG 80
Air inlet Pipe MM 50
Air outlet Pipe MM 60
Heat Area M2 50
Automatic Burning Time (Min-Max.) H 15/24
Fuel Wood Pellet
Consumption for Pellet (Min-Max) KG/H 0.5/0.9
Efficiency % 80%
Hopper Capacity KG 12
Electronic consumption W/H 100-400
Rating Voltage and Frequency V/HZ 230/50-115/60-100/50
Rating Power KW 6
Thickness of steel, inside: MM 3
Thickness of steel, outside: MM 1.5-2
APPEARANCE CHOICES
The STOVE can be ordered with the following sides and doors color:
Black Red Beige
