Graco 015.050-DP - DISPLACEMENT PUMP 000.035-DO; DISPLACEMENT PUMP 000.050-DO

-
7 - B.6.20.44.-EO
F22.060.03, issued on 01.98
DISPLACEMENT PUMP 000.035-DO
List of repair parts, seals Part No. 79978 906153
Pos 90 1 off Stuffin
g
complete. 24.5 x 42.7 x 19.2
Pos 120 1 off Flat packing D73.5 x T1
Pos 170 1 off Stuffing complete 34.4 x 49.2 x 16.7
Pos 210 1 off Seal washer 53 x 55.8 x 1.4
List of repair parts, decant valve , Displacement pump Part No. 79978 906154
Pos 30 1 off Profile sealin
g
rin
g
16 x 19 x 1.9
Pos 40 1 off Valve seat D 12
Pos 50 1 off Seal washer 21.8 x 25.2 x 2.2
Pos 60 1 off Ball 16mm I
Pos 210 1 off Seal washer 53 x 55.8 x 1.4
List of repair parts, suction valve, Displacement pump Part No. 79978 906155
Pos 230 1 off Profile sealin
g
rin
g
20 x 24 x 2.4
Pos 240 1 off Valve seat D 14,5
Pos 250 1 off Seal washer 33.2 x 36 x 1.5
Pos 260 1 off Ball 20 mm I
List of repair parts, level indicator, Displacement pump Part No. 79978 906056
Pos 270 1 off Level indicator for deter
g
ents
Pos 280 1 off O-ring 14 x 4 B
Pos 290 1 off O-ring 10 x 2 B
Sin
g
le part, step piston, Displacement pump Part No. 76598 010002
Pos 10 1 off Step piston D34.5 / D24.6
Sin
g
le part, Ban
j
o bolt, Displacement pump Part No. 76031 053002
Pos 20 1 off Ban
j
o bolt M27 x 1.5 x 24
DISPLACEMENT PUMP 000.050-DO
List of repair parts, seals Part No. 79978 906202
Pos 90 1 off Stuffin
g
complete 29.1 x 47.1 x 19
Pos 120 1 off Flat packing D77.5 x T1
Pos 170 1 off Stuffing complete. 40.9 x 55.1 x 16.5
Pos 210 1 off Seal washer 58.5 x 61.3 x 1.4
List of repair parts, decant valve , Displacement pump Part No. 79978 906203
Pos 30 1 off Profile sealin
g
rin
g
20 x 24 x 2.4
Pos 40 1 off Valve seat D 14.5
Pos 50 1 off Seal washer 27.8 x 31.2 x 2.2
Pos 60 1 off Ball 20 mm I
Pos 210 1 off Seal washer 58.5 x 61.3 x 1.4
List of repair parts, suction valve, Displacement pump Part No. 79978 906204
Pos 230 1 off Profile sealin
g
rin
g
23 x 27 x 2.5
Pos 240 1 off Valve seat D 18,5
Pos 250 1 off Seal washer 40.2 x 43 x 1.5
Pos 260 1 off Ball 25 mm I
List of repair parts, level indicator, Displacement pump Part No. 79978 906056
Pos 270 1 off Level indicator for deter
g
ents
Pos 280 1 off O-ring 14 x 4 B
Pos 290 1 off O-ring 10 x 2 B
Sin
g
le part, step piston, Displacement pump Part No. 76598 007002
Pos 10 1 off Step piston
D41 / D29.2
Sin
g
le part, Ban
j
o bolt, Displacement pump Part No. 76031 059002
Pos 20 1 off Banjo bolt M33 x 1.5 x 24
