Pos Description Material Notes Item ID
Compr. air conn. 1001 Safety valve - G¼ PN 8 75591 008006
1002 Sound absorber - G ½ 75665 007005
1003 Union complete - D 15.5-M22x1.5 77638 002003
1004 Air pressure connection complete - D15.5 G 3/8 77631 015002
1005 Ball valve complete - PN 50 R 3/8-G 3/8 77601 013002
1006 Nipple reduction - 8 R 3/8 tap. – M22x1.5 76639 208001
1007 Air pressure connection complete - R 3/8 for gun 77522 011003
1008 Air pressure connection complete - R 3/8 for gun with filter 77522 007003
1009 Elbow - R ¼ tap. – M14x1 75214 006002
1010 Nipple reduction - 6-G ¼ A-M14x1 76639 014001
1011 Bolted connection -W - R ¼ tap. – 8 75202 001008
Grounding 1012 Grounding wire - Length 8m 73483 001011
Suction connection 1013 Nipple reduction SST M 26x1.5 x G3/4 77741 130002
1014 Screwed joint SST GE 22 – ZLR ED 75204 010002
1015 Niple reduction SST With ball valves, StZn 77741 022002
1016 Nipple reduction SST M 26x1.5 x D22 77741 131002
1017 Suction hose SST D22 30l container 78848 020006
1018 Suction hose SST D22 200l container 78848 020007
1019 Cup, complete. SST 5l – D22 77683 057002
1020 Suction hose SST 1000mm long/D22 77848 035009
1021 Suction hose SST 1600mm long/D22 77848 035010
1022 Seal washer Al A 27x32 74188 025070
1023 Fixing screw St/Zn G ¾ A 74035 013003
1024 Detachable double nipple CS/NI R3/8 tap. – G3/4 77240 004002
Pressure connection 1025 Seal washer SST 17 x 22 x 3 76188 105003
1026 Seal washer SST 17 x 21 74188 015090
1027 Back pressure valve SST G 3/8 – DN 8 PN 350 78586 008002
1028 Hexagonal nut SST G 3/8 – 25 long 76074 030001
1029 Pipe complete SST G 3/8 – G 1/4 PN 360 77796 063003
1030 Manometer CuZn 0 - 160 bar 75782 012001
1031 Manometer CuZn 0 - 250 bar 75782 013001
1032 Seal washer SST 14 x 18 74188 012090
1033 Nipple reduction SST G 3/8 - G 1/4 76641 017001
1034 Nipple reduction SST G 3/8 - G1/4 76639 016003
1035 Nipple reduction SST G 3/8 76640 005001
1036 Pressure control valve SST
P 100 – VM; PE 180 79637 009002
1037 Pressure control valve SST P 200 – VM; PE 360 79637 010001
Order Example
a) Further information on request
b) Replacement O-Ring Item ID 74186 025020
for Pos. 1003 and 1004
c) Replacement O-Ring Item ID 74186 026020
for Pos. 1013, 1015 and 1016
d) Replacement washer Item ID 75188 097002
for Pos. 1014, 1015 and 1016
e) Replacement sealing ring Item ID 76188 014002
for Pos. 1019
f) For fluid screen see page 1
g) Hose connection G 1/4
h) Hose connection G 3/8
i) Hose connection either G 1/4 or G 3/8
B.6.20.44-A
3
Please lay out each order as follows:
Description Pos. No. Part No.
Reciprocating pump 015.050-DP 002
79042 062002
