Replacement Parts
3A2854G 19
Parts List - 16N661, 16N662, 16N663, 16N667, 16P122, 16W104, 17C242, 17C811
Ref.
If you have this model sprayer
(model number is the same as the part number,
which is below the handle)
Order Part
Number:
Description
1 All models 243103 Pump Armor (32 oz)
2 Model 16N667, 17C811 16M816 Startup/Storage Kit
Models 16N661, 16N662, 16N663, 16P122,
16W104, 17C242
16P358 Startup/Storage Kit
3 Model 16N667, 17C811 24F078 Blue Storage Case (Not included with all models)
Models 16N663, 16P122 16P463 Black Storage Case (Not included with all models)
5 Model 16N667, 17C811 PST211 211 Spray Tip/Guard Assembly
Model 16N667, 17C811 PST213 213 Spray Tip/Guard Assembly
Model 16N667, 17C811 PST315 315 Spray Tip/Guard Assembly
Model 16N667, 17C811 PST411 411 Spray Tip/Guard Assembly
Model 16N667, 17C811 PST413 413 Spray Tip/Guard Assembly
Model 16N667, 17C811 PST515 515 Spray Tip/Guard Assembly (included with model 16N667,
17C811)
Model 16N667, 17C811 PST517 517 Spray Tip/Guard Assembly
6 All models 24E376 1 pack Spray Tip Filter
All models 24F039 3 pack Spray Tip Filter
7 All models 108195 Needle Assembly O-ring
8 Models 16N661, 16N662, 16N663, 16P122,
16W104, 17C242
262438 Needle Assembly Kit: includes parts 7 (qty. 2), 8
Model 16N667, 17C811 262437 Needle Assembly Kit: includes parts 7 (qty. 2), 8
9 All models 115478 Screw
10 All models 16M867 Complete Pump Assembly w/Adjustable Prime/Spray Valve:
includes parts 10, 11-17, 20, 24-28, 44, 55
All models 16T447 Pump Housing Only: includes parts 10, 20, 26, 27, 44, 55
11 All models 262602 Inlet valve Repair Kit; includes 11, 12, 13
12 All models 262602 Inlet valve Repair Kit; includes 11, 12, 13
13 All models 262602 Inlet valve Repair Kit; includes 11, 12, 13
14 All models 109576 O-ring
15 All models 119790 O-ring
16 All models 16P151 Inlet/Outlet Valve Repair Kit: includes parts 11-17, 24
17 All models 106553 Suction Tube O-ring
18 Models 16N663, 16P122 16P465 Enclosure Replacement Kit:
includes parts 20, 32, 34-37, 38 (qty. 10), 39, 44, 55
Model 16N662 16P466 Enclosure Replacement Kit:
includes parts 20, 32, 34-37, 38 (qty. 10), 39, 44, 55
Models 16N661, 16N667, 16W104, 17C242,
17C811
16P473 Enclosure Replacement Kit:
includes parts 20, 32, 34-37, 38 (qty. 10), 39, 44, 55
19 Models 16N663, 16P122 16P465 Enclosure Replacement Kit:
includes parts 20, 32, 34-37, 38 (qty. 10), 39, 44, 55
Model 16N662 16P466 Enclosure Replacement Kit:
includes parts 20, 32, 34-37, 38 (qty. 10), 39, 44, 55
Models 16N661, 16N667, 16W104, 17C242,
17C811
16P473 Enclosure Replacement Kit:
includes parts 20, 32, 34-37, 38 (qty. 10), 39, 44, 55
20 All models 16E403 Sprayer Cup Seal
21 All models 16P121 Flexible Suction Tube Kit: includes parts 17 (qty. 2), 21, 22
22 All models 16N522 Flexible Suction Tube Strainer
(Parts List continues on next page)
To Next Page
