Graco 17M363 - Technical Specifications

Technical Specifications
3A4749D 35
Technical Specifications
Cordless HandHeld Sprayer
U.S. Metric
Max Working Pressure 2000 psi 14 MPa, 138bar
Weight
5.25 lb 2.4 kg
Dimensions:
Length
14.0 in. 36.1 cm
Width
5 in. 12.7 cm
Height
10.5 in. 26.7 cm
Storage Temperature Range ◆❖ 32° to 113° F 0° to 45° C
Operating Temperature Range ✓ 40° to 90° F 4° to 32° C
Storage Humidity Range 0% to 95% relative humidity, non-condensing
Sound Pressure Level
86.0 dBa
Sound Power Level† 90.7 dBa, Uncertainty = 0.5 dBa
Vibration Level (measured in
accordance with EN 50580:2012)
Vibration total value
a
h
= 33.2 ft/s
2
Uncertainty = 0.5 m/s
2
Vibration total value
a
h
= 10.1 m/s
2
Uncertainty = 0.2 m/s
2
Charger Power Source
17N167 100 Vac, 50 Hz, 15A, 1 Ø
17M366, 17M364, 17P519,
17N220, 17N221, 17P520
230 Vac, 50 Hz, 16A, 1 Ø
Battery
Voltage (DC)
20 V MAX* 2.0 Ah Li-ion
Compact Battery Pack DEWALT
Maximum tip orifice 0.016 in. 0.41mm
◆ Pump damage will occur if fluid freezes in pump.
❖ Damage to plastic parts may result if impact occurs in low temperature conditions.
✓ Changes in paint viscosity at very low or very high temperatures can affect sprayer performance.
† All readings were taken within the priming mode at the assumed operator position. Sound power levels
were tested to ISO 3741 at 3.3 feet (1m).
* Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18.
