Repair
334599L 11
8. Remove and discard throat packing
and glands from the cylinder.
Assemble Pump
1. Soak leather packings in SAE 30W oil for
one hour before assembly.
ti24880a
Leather
Packings
ti24890a
Leather
Packings
ti24893a
