Graco 231-825 - Page 26

 
Drive Housing, Connecting Rod, Crankshaft
Fig. 23
1
Torque
to 21 in–lb (2.4 N.m)
3
2 Quantity of three
Quantity of one
Apply a total of
3 fl. oz.(89 cc) of
grease
to gears.
4
56
6
19
15
13
64
11
5,6
12a
12
12b
59
11a
4a
A
34
31
REF A
16
47
Note: Filter
not shown
02815
1
1
2
3
4
C
