Technical Specifications
311209W 19
Technical Specifications
California Proposition 65
Hot Melt Dispense Guns
U.S. Metric
Maximum operating temperature 400 °F 204 °C
Maximum fluid working pressure 5000 psi 34.5 MPa, 345 bar
Outlet port size 5/8-18 UNF-2B
Inlet port size on gun housing 7/8-14 UNF- 2B
Inlet port size on fluid swivel 7/8-14 JIC(m)
Voltage 230/240 Vac
Wattage 120 W
Resistance temperature detector
(platinum RTD; 0.00385 ohm/ohm/°)
108.2 ohms @ 70 °F 108.2 ohms @ 21 °C
Heater resistance Individually: 890 ohms, +/- 70 ohms
Wired in parallel: 445 ohms, +/- 35ohms
Weight Without swivel: 2.7 lb
With swivel: 3.4 lb
Without swivel: 1.2 kg
With swivel: 1.5 kg
Dimensions Height: 7.5 in.
Width: 3.0 in.
Length:
Models 249514 and 249515: 9.0 in.
Models 249512 and 249513: 10.5 in.
Height: 191 mm
Width: 76 mm
Length:
Models 249514 and 249515: 229 mm
Models 249512 and 249513: 267 mm
Wetted parts Aluminum, fluorocarbon rubber, stainless steel, PTFE, carbon steel, brass
Notes:
All trademarks or registered trademarks are the property of their respective owners.
CALIFORNIA RESIDENTS
WARNING: Cancer and reproductive harm – www.P65warnings.ca.gov.
