Parts
26 3A0732B
Package Parts
Ref.
No. Description
Package
Qty24F150 24F151 24F152 24F153 24F154 24F155 24F156 24F157 24F158 24F159
1 BRACKET, wall 24H102 24H102 24H102 24H102 24H102 24H102 24H102 24H102 24H102 24H102 1
2 KIT, stand; includes
items 3, 4, 5, 6, and 43
below, and 418 on page
36
24F164 24F164 24F164 24F164 24F164 1
3PLUG
108175 108175 108175 108175 108175 4
4 SCREW, cap, hex hd;
1/4-20 x 1.5 in. (38 mm)
100058 100058 100058 100058 100058 6
5 SPACER, tube
--- --- --- --- ---
4
6 NUT, hex; 1/4-20
GC2095 GC2095 GC2095 GC2095 GC2095 6
7 MOTOR, air; see page
32
24G693 24G693 24G694 24G694 24G694 24G694 24G694 24G694 24G693 24G693 1
8 KIT, rod, tie; includes
rods and items 11 and
17 (3 of each)
24G707 24G707 24G707 24G707 24G707 24G707 24G707 24G707 24G707 24G707 1
9 SPRING, safety 24H103 24H103 24H103 24H103 24H103 24H103 24H103 24H103 24H103 24H103 1
10 ADAPTER, pump lower 24H104 24H104 24H104 24H104 24H104 24H104 24H104 24H104 24H104 24H104 1
11 NUT, lock 104541 104541 104541 104541 104541 104541 104541 104541 104541 104541 3
12 LOWER, pump; see
page 30; also includes
items 15, 18, and 19
24G701 24G701 24G702 24G702 24G701 24G701 24G701 24G701 24G702 24G702 1
13 NUT, jam 195150 195150 195150 195150 195150 195150 195150 195150 195150 195150 1
15
‡
NIPPLE; 1/4 npsm x 1/4
npt; plated steel
162453 162453 162453 162453 162453 162453 1
NIPPLE; 1/4 npsm x 1/4
npt; sst
166846 166846 166846 166846 1
16 KIT, suction hose, 5 gal.
(19 l); 3/8 in. (10 mm)
OD; includes items 37
(qty 1), 38, and 42
24F148 24F148 24F148 24F148 24F148 24F148 24F148 24F148 24F148 24F148 1
17 NUT, hex; 7/16-20 Not sold separately. Order Tie Rod Kit, item 8. 3
18
‡
PIN, straight 196762 196762 196762 196762 196762 196762 196762 196762 196762 196762 1
19
‡
SPRING, retaining 196750 196750 196750 196750 196750 196750 196750 196750 196750 196750 1
