Parts

3A0732B 27

‡ Included in Pump Lower Rebuild Kit. See page 31.

20 AIR CONTROL ASSEM-

BLY; see page 36

24H162 24H163 24H162 24H163 24H164 24H165 24H162 24H163 24H162 24H163 1

21 ELBOW, swivel; 1/4

npt(m) x 3/8 in. (10 mm)

OD tube

121141 121141 121141 121141 121141 121141 121141 121141 121141 121141 1

22 TUBE, polyurethane;

3/8 in. (10 mm) OD; 2 ft

(0.61 m)

24H008 24H008 24H008 24H008 24H008 24H008 24H008 24H008 24H008 24H008 1

23 SCREW, ground 116343 116343 116343 116343 116343 116343 116343 116343 116343 116343 1

26 WIRE, grounding 238909 238909 238909 238909 238909 238909 238909 238909 238909 238909 1

28 THROAT SEAL LIQUID;

4 oz (not shown)

238049 238049 238049 238049 238049 238049 238049 238049 238049 238049 1

37 STRAINER, suction; 3/8

in. (10 mm) OD tube;

pack of 3

24F160 24F160 24F160 24F160 24F160 24F160 24F160 24F160 24F160 24F160 1

38 O-RING; fluoroelasto-

mer

117559 117559 117559 117559 117559 117559 117559 117559 117559 117559 1

42 NUT, jam, suction 15E813 15E813 15E813 15E813 15E813 15E813 15E813 15E813 15E813 15E813 1

43 WASHER, lock; 1/4;

part of stand kit (2)

--- --- --- --- ---

Ref.

No. Description

Package

Qty24F150 24F151 24F152 24F153 24F154 24F155 24F156 24F157 24F158 24F159
