Warnings

WARNING WARNING

WARNING

INTRINSIC INTRINSIC

INTRINSIC

SAFETY SAFETY

SAFETY

Intrinsicallysafeequipmentthatisinstalledimproperlyorconnectedtonon-intrinsicallysafe

equipmentwillcreateahazardousconditionandcancause󰘰re,explosion,orelectricshock.

Followlocalregulationsandthefollowingsafetyrequirements.

•InstallationshouldbeinaccordancewithANSI/ISARP12.06.01“InstallationofIntrinsically

SafeSystemsforHazardous(Classi󰘰ed)Locations”andtheNationalElectricalCode®

(ANSI/NFPA70).

•InstallationinCanadashouldbeinaccordancewiththeCanadianElectricalCode,CSA

C22.1,Part1,AppendixF.

•ForATEX,installperEN60079–14andapplicablelocalandnationalcodes.

•Equipmentthatcomesincontactwithintrinsicallysafeterminalsmustmeettheentity

parameterrequirementsspeci󰘰edinControlDrawing16M169.SeeAppendixAinManual

332013.Thisincludessafetybarriers,DCvoltagemeters,ohmmeters,cables,and

connections.Removetheunitfromthehazardousareawhenservicing.

•Withoutthesafetybarrier,theequipmentisnolongerintrinsicallysafeandmustnotbe

operatedinhazardouslocations,asde󰘰nedinarticle500oftheNationalElectricalCode

(USA)oryourlocalelectricalcode.

•Donotinstallequipmentapprovedonlyfornon-hazardouslocationinahazardousarea.See

theIDlabelfortheintrinsicsafetyratingforyourmodel.

•Donotuseintrinsicallysafeequipmentwithapowersupplythathasnobarrier.Intrinsic

safetymaybecompromised.

•Groundthepowersupply.Avoltagelimitingsafetybarriermustbeproperlygroundedtobe

effective.Forpropergrounding,usea12gaugeminimumgroundwire.Thebarrier’sground

mustbewithin1ohmoftrueearthground.

•Donotremoveanycoveruntilpowerhasbeenremoved.

•Donotsubstitutesystemcomponentsasthismayimpairintrinsicsafety.

3A6948A13
