Graco 24L097 Instructions-Parts List

Troubleshooting
Battery Battery
Battery
Replacement Replacement
Replacement
Procedure Procedure
Procedure
Replacethebatteryonlyiftheclockstopsfunctioning
afterdisconnectingpowerorapowerfailure.
Sparkingcanoccurwhenchangingthebattery.
Replacethebatteryonlyinanon-hazardous
location,awayfrom󰘱ammable󰘱uidsorfumes.
NOTICE NOTICE
NOTICE
Toavoiddamagetothecircuitboard,wearPartNo.
112190groundingstrap,andgroundappropriately.
1.Disconnectpower.
2.Removethemodulefromthebracket.
3.Attachthegroundingstrap.
4.Remove4screws,andthenremovetheaccess
cover.
5.Usea󰘱atheadscrewdrivertopryouttheold
battery.
NOTE: NOTE:
NOTE:
Disposeofbatteryproperlyinan
approvedcontainerandaccordingtoapplicable
localguidelines.
6.Replacewithnewbattery.Ensurebattery󰘰ts
underconnectortabsbeforesnappingotherend
inplace.
NOTE: NOTE:
NOTE:
UseonlyPanasonicCR2032batteriesfor
replacement.
7.Reassembleaccesscoverandscrews.
8.Snapthemodulebackintothebracket.
3A6948A61

Graco 24L097 Specifications

General

Brand	Graco
Model	24L097
Category	Control Unit
Language	English
