Graco 309707N - Page 7

7309707
Parts List - Sprayer
234182, 234439
Ref
No. Part No. Description Qty
Ref
No. Part No. Description Qty
1 107434 BEARING, thrust 1
2 117828 PACKING, o–ring 1
3 111457 PACKING, o–ring 1
4 111600 PIN, grooved 1
5 111699 GASKET, seat, valve 1
8 116073 WASHER, thrust 1
9 116074 WASHER, thrust 1
10 116079 BEARING, thrust 2
12 117501 SCREW, mach, hex washer hd 6
14 103413 O–RING 2
15 15B067 MANIFOLD, ST Pro 1
16 246384† FILTER, fluid, 60 mesh 1
17 287167 CAP, manifold 1
20 15B120 GROMMET, transducer 1
22 287058 COVER, front, Graco, paint; 1
includes 12
23 287056 SHIELD, motor, painted; 1
includes 12, 63, 65
24 162453 NIPPLE, (1/4 npsm x 1/4 npt) 2
25 180131 BEARING, thrust 1
26 187615 SEAT, valve 1
27 187625 HANDLE, valve, drain 1
29 195150 NUT, jam, pump 1
31 196750 SPRING, retaining 1
32 196762 PIN, straight 1
33 206994 FLUID, TSL 1
35 235014 VALVE, drain 1
includes 5, 26
36 224807 BASE, valve 1
38 243222 TRANSDUCER, pressure control 1
includes 3
39 241920 DEFLECTOR, threaded 1
40 287057 GEAR, reducer 1
includes 8, 10
41 246428 PUMP, displacement, ST 1
42 287055 HOUSING, drive 1
includes 12, 47
43 287053 ROD, connecting 1
includes 31, 32
44 GEAR, crankshaft; includes 1, 9, 25
287054 495 1
248231 595 1
45 287003 HOSE, cpld 1
46 240794 HOSE, cpld, 1/4 in. x 50 ft, unpkg 1
47 117493 SCREW, mach, hex washer hd 10
52 LABEL, front, Graco
15B372 395 1
15B255 495 1
15D161 595 1
53 LABEL, side, Graco
15B847 395 1
15B495 495 1
15D165 595 1
54 MOTOR, 240V; includes 77
287061* 495 1
248185‡ 595 1
55 244240 HOSE, drain; includes 39 1
57 246385 STRAINER, 7/8–14 unf 1
59 245984 FRAME, cart, HI 1
60 246387 TUBE, suction 1
includes 14, 57, 69, 84
61 246540 GUN, includes Manual 309639 1
62 276888 CLIP, drain line 1
63 15B517 LABEL, danger 1
65 195792 LABEL, warning 1
66 108068 PIN 2
67 109032 SCREW, pan hd 4
68 111590 BUTTON, snap 2
69 15B434 NUT, jam 1
70 15C146 HOOK, pail 1
71 115979 PLUG, hole 1
72 183350 WASHER 1
73 192027 SLEEVE, cart 2
74 245245 HANDLE 1
75 108691 PLUG, tubing 2
76 115099 WASHER 1
77 FAN, motor
239912 495 1
248189 595 1
81 106062 WHEEL 2
82 15B999 CLIP, retaining 2
83 104811 CAP, hub 2
84 15B652 WASHER, suction 1
Extra Danger and Warning tags and labels available free.
* Motor Brush Kit 287016 is available
‡ Motor Brush Kit 248186 is available
† Other filters available: 246382, 100 mesh; 246383, 200
mesh; 246425, 30 mesh
