Graco 312585G - Parts Listings

Parts
18 312585G
Parts Listings
Common Parts
The following parts except #39, are used on all packages in this manual.
*Assemblies 258664 and 258665 do not include item 39
and contain Qty. 2 of item 41.
† The first two digits designate the fan angle. The last
three digits designate the orifice size in thousandths of
an inch.
Parts that Vary by Package
Ref. Part Description Qty.
4 100133 WASHER, lock; 3/8 4
8 244524 WIRE, ground 1
12 101712 NUT, lock; 5/8-11 3
16 101748 PLUG, pipe; 3/8 npt; sst 1
17 15T272 COUPLING, quick release; 3/8 npt 1
19 15T273 SWIVEL; 90°; 1 in. npt(m) x
1 in. npsm(f)
1
20 214959 HOSE, suction; 1 in. (25 mm) ID;
1 in. npt(m) sst fittings;
6 ft (1.83 m); nylon
1
21 166629 COUPLING; 1 in. npt(fbe) 1
22 166630 TUBE, suction; 1 in. (25 mm) ID;
1 in. npt(mbe); brass
1
23 205770 HANGER, pipe 1
24 100085 SCREW, thumb; 1/4-20 x
1/2 in. (13 mm)
1
25 15T284 STRAINER, fluid inlet; 60 mesh 1
26 247879 GUN, wand; sst and brass;
includes 32 in. (813 mm) sst wand;
see 308511
1
30 247878 HOSE, fluid; 3/8 in. (10 mm) ID;
sst quick disconnect fittings (m x f);
50 ft (15.2 m)
1
37 805584 TIP, spray, Q-type; 15090† 1
38 805538 TIP, spray, Q-type; 40030† 1
39* 805575 TIP, spray, Q-type; 00080 † 1
40 805549 TIP, spray, Q-type; 25045† 1
41* 805566 TIP, spray, Q-type; 40065 † 1
68 113498 VALVE, safety,
110 psi (0.76 MPa, 7.6 bar)
1
Ref. Part Description Qty.
Ref.
No. Description
Package Part Nos.
Qty247549 247550 247551 247552 247553 247554 258664 258665
1 CART; includes items 1a-1d 287884
287884 287884 287884 1
1a CAP, tube, round 113361 113361 113361 113361 2
1b WHEEL, semi-pneumatic 113362
113362 113362 113362 2
1c WASHER; 3/4 in. (19 mm) ID buy
locally
buy
locally
buy
locally
buy
locally
2
1d RING, retaining 113436
113436 113436 113436 2
2 SPACER 15K296 15K296 15K296 15K296 1
3 SPACER, mounting 120465
120465 120465 120465 4
5 NUT, hex; 3/8-16 100131 100131 100131 100131 4
6 MOTOR, air; see 311238 N34DN0 N34DN0 N65DN0 N65DN0 N65DN0 N65DN0 N65DN0 N65DN0 1
7 REGULATOR, air, assembly;
see page 20.
24E013 24E025 24E013 24E025 24E013 24E025 24E013 24E025 1
9 ROD, tie; 14.656 in. (372 mm)
shoulder to shoulder
15T274 15T274
3
ROD, tie; 15.4 in. (391 mm)
shoulder to shoulder
15H562 15H562 15H562 15H562 15H562 15H562 3
