Graco 312585G - Wall Mounting Bracket Diagram

Wall Mounting Bracket Diagram
22 312585G
Wall Mounting Bracket Diagram
TI8614B
9.0 in.
(228.6 mm)
1.6 in.
(41.4 mm)
12.4 in.
(314.3 mm)
1.0 in.
(25.4 mm)
5.3 in.
(133.4 mm)
14.5 in.
(368.3 mm)
17.8 in.
(450.9 mm)
2.0 in.
(50.8 mm)
5.4 in.
(136.5 mm)
7/16 in. (11 mm)
diameter holes for
mounting to wall
1/2 in. (12.7 mm) diameter
holes for mounting to stand
7.4 in.
(187.3 mm)
11.75 in.
(298.5 mm)
