Pump Performance Tables
24 312585G
Pump Performance Tables
12:1 Ratio Pumps (247549, 247550)
23:1 Ratio Pumps (247551, 247552)
Fan
Angle
(˚)
Spray Tip
Orifice
Size
40 PSI (0.3 MPa, 3 bar) Air Supply 70 PSI (0.5 MPa, 5 bar) Air Supply 100 PSI (0.7 MPa, 7bar) Air Supply
gpm
(l/min)
cfm
(m³/min)
Working
Pressure in
PSI (MPa,
bar) gpm (l/min)
cfm
(m³/min)
Working
Pressure in
PSI (MPa,
bar) gpm (l/min)
cfm
(m³/min)
Working
Pressure in
PSI (MPa,
bar)
40 .030 (0.76) 1.00 (3.79) 7.86 (0.22)
450.90
(3.11,31.09) 1.33 (5.03) 16.50 (0.47)
808.68
(5.58, 55.76) 1.56 (5.91) 26.73 (0.76)
1144.56
(7.89, 78.91)
25 .045 (1.14) 1.48 (5.60) 11.32 (0.32)
450.85
(3.11, 31.09) 1.96 (7.42) 23.12 (0.65)
799.81
(5.51, 55.14) 2.33 (8.82) 38.46 (1.09)
1131.36
(7.80, 78.00)
40 .065 (1.65) 2.06 (7.80) 15.61 (0.44)
442.42
(3.05,30.50) 2.73 (10.33) 32.59 (0.92)
786.54
(5.42,54.23) 3.21 (12.15) 51.15 (1.45)
1111.41
(7.66, 76.63)
00 .080 (2.03) 2.49 (9.43) 18.84 (0.53)
449.22
(3.10, 30.97) 3.24 (12.26) 37.98 (1.07)
780.26
(5.38, 53.80) 3.79 (14.35) 60.29 (1.71)
1080.19
(7.45, 74.48)
15 .090 (2.29)
2.89
(10.94) 22.77 (0.64)
434.62 (3.00,
29.97) 3.54 (13.40) 40.51 (1.15)
770.16
(5.31, 53.10) 4.15 (15.71) 65.06 (1.84)
1079.40
(7.44, 74.42)
Fan
Angle
(˚)
Spray Tip
Orifice
Size
40 PSI (0.3 MPa, 3 bar) Air Supply 70 PSI (0.5 MPa, 5 bar) Air Supply 100 PSI (0.7 MPa, 7bar) Air Supply
gpm (l/min)
cfm
(m³/min)
Working
Pressure in
PSI (MPa,
bar) gpm (l/min)
cfm
(m³/min)
Working
Pressure in
PSI (MPa,
bar) gpm (l/min)
cfm
(m³/min)
Working
Pressure in
PSI (MPa, bar)
40 .030 (0.76) 1.36 (5.15) 17.99 (0.51)
817.94
(5.64, 56.39) 1.79 (6.78) 37.16 (1.05)
1443.83
(9.95, 99.55) 2.08 (7.87) 57.34 (1.62)
2023.76
(13.95, 149.33)
25 .045 (1.14) 1.97 (7.46) 26.14 (0.74)
800.94
(5.52, 55.22) 2.58 (9.77) 51.62 (1.46)
1380.41
(9.52, 95.18) 2.99 (11.32) 80.34 (2.27)
1896.54
(13.08, 130.76)
40 .065 (1.65) 2.72 (10.30) 34.54 (0.98)
782.76
(5.40, 53.97) 3.41 (12.91) 67.09 (1.90)
1297.65
(8.95, 89.47) 3.91 (14.80) 103.85 (2.94)
1748.72
(12.06, 120.57)
00 .080 (2.03) 3.11 (11.77) 40.19 (0.44)
738.16
(3.05, 30.50) 4.01 (10.33) 78.96 (0.92)
1218.27
(5.42, 54.23) 4.54 (12.15) 119.29 (1.45)
1638.03
(7.66, 76.63)
15 .090 (2.29) 3.41 (12.91) 43.96 (1.24)
727.05
(5.01, 50.13) 4.17(15.79) 84.47 (2.39)
1179.52
(8.13, 81.33) 4.92 (18.62) 127.22 (3.60)
1589.38
(10.96, 109.58)
