Graco A Series Repair And Parts

4 309662
Component Description
Compressor Requirements
NOTE: This sprayer requires an external air compressor.
Air compressor range: 5 scfm to 35 scfm, 30 to 100 psi (0.2–0.76 MPa, 2 to 7.6 bar)
2 gpm Desired Fluid Flow 3 gpm Desired Fluid Flow
Material
Air Requirements*
Minimum
Compressor Size
Air Requirements*
Minimum
Compressor Size
Elastomerics
(textured)
25 scfm at 90 psi
(0.7 m
3
/min at 0.63
MPa, 6.3 bar)
15 HP 30 scfm at 90 psi
(0.84 m
3
/min at 0.63
MPa, 6.3 bar)
18 HP
Simulated
Accoustical
15 scfm at 60 psi
(0.42 m
3
/min at 0.42
MPa, 4.2 bar)
8 HP 20 scfm at 60 psi
(0.56 m
3
/min at 0.42
MPa, 4.2 bar)
10 HP
Splatter Coat and
Knockdown
10 scfm at 40 psi
(0.28 m
3
/min at 0.28
MPa, 2.8 bar)
5 HP 15 scfm at 40 psi
(0.42 m
3
/min at 0.28
MPa, 2.8 bar)
15 HP
Orange Peel 15 scfm at 60 psi
(0.42 m
3
/min at 0.42
MPa, 4.2 bar)
8 HP 20 scfm at 60 psi
(0.56 m
3
/min at 0.42
MPa, 4.2 bar)
10 HP
* Material, temperature and volume affect cfm needed to properly atomize material.
Maintenance
CAUTION
For detailed engine maintenance and specifica-
tions, refer to separate HONDA engine manual.
CAUTION
Close black fuel shutoff lever whenever you are
transporting sprayer to prevent fuel from flooding
engine.
Keep sprayer upright and level when operating it
and when transporting it. This prevents crankcase
oil from leaking into combustion chamber, which
makes startup very difficult
Daily: Check engine oil level and fill as needed.
Daily: Check and fill gas tank.
After first 20 hours of operation and each 100
hours thereafter: Change oil.
Weekly: Remove air filter cover and clean element.
In very dusty environments, check filter daily. Replace
element as needed. Replacement elements can be
purchased from your local HONDA dealer.
Spark plug: Use only a (NGK) BP6ES or BPR6ES
plug. Gap plug to 0.025 to 0.030 in. (0.7 to 0.8 mm).
Always use a spark plug wrench.
