Graco A Series Repair And Parts

309662 9
Pump Repair
TI3015A
Fig. 5
205*
205*
221
217
214
216*
215
219*
207*
208*
206
*209
*211
*210
*218
212
220*
202
*226
*203
*204
225*
201
3
5
10
7
8
227
2
1
2
Grease inside of throat
before installing packings
3
1
Lips of v-packings in throat
must face down
Grease inside of packings
after installing
32
5
6
Lips of v-packings on
piston must face up
7
6
Grease outside of packings
after installing
8
Lips of u-cup seal on
piston must face down
9
If piston seat and rod were
separated, apply Loctite primer,
then red Loctite, and torque to
80–100 ft–lb (110–135 N.m)
10
9
Tighten with hammer
Torque piston housing to piston seat
(213) to 90–125 ft–lb (122–170
N.m) without changing alignment of
packing nut
76
TI3015A
