11
Use the top tether strap when
using forward-facing (A)
When used properly, the top tether
helps reduce injury in a sudden
stop or crash.
Review section 3
Car Seat Does Not Move More
than 1” (2.5 cm) at the Belt
Path (B)
Review section 3
Harness Straps at or Just
Above Child’s Shoulders (C)
Review section 3
Chest Clip Even With Armpits (D)
Review section 3
Cannot Pinch Harness Straps
at the Shoulder (E)
Review section 3
Forward-Facing Installation
B
A
D E
C

Graco Atlas Specifications

General

Recline Positions	6
Cup Holders	2
Harness Type	5-point harness
Machine Washable	Yes
Rear-Facing Weight Limit	5-40 lbs
Forward-Facing Weight Limit	22-65 lbs
Headrest Positions	10
Warranty	1 year limited warranty
Installation	LATCH system and seat belt
Safety Features	Side-impact protection
Harness Positions	10
Type	Convertible Car Seat
