Graco Eagle C Series User Manual

19308-262
Displacement Pump Service
Fig. 9
101
109
108
107
111*
105*
106
104
*103
102 (REF)
102
107 (REF)
2
3
4
Torque
to 15 to 20 ft-lb (20 to 27 N-m).
Lubricate.
T
orque to 35 to 45 in-lb (4.0 to 5.1 N-m).
5
Assemble pin (1 12*) flush or below surface.
Flat side must face retainer (106).
6
Large bevel must face piston (104).
7
Lubricate inside diameter .
01971
1
7
25
4
2
2
2
2
6
3
1
112*
