Graco Eagle C Series User Manual

Port Sizes (All Models)
E 3/8 npt(f) Air Inlet
F 1/4 npt(f) Fluid Outlet
A
B
C
D
E
F
01973
Four 0.281 in. (7.1 mm)
diameter holes
5.67 in. (144 mm)
diameter
2.02 in. (51.3 mm)
diameter
2.5 in.
(63.5 mm)
2.125 in.
(54 mm)
Mounting Hole
Layout
01965A

Dimensions
Model No. A B C D Weight
235–888 27.369 in.
(695 mm)
17.489 in.
(444 mm)
9.88 in.
(251 mm)
7.102 in.
(180 mm)
1 1 lb
(5.0 kg)
235–889 36.619 in.
(930 mm)
26.739 in.
(679 mm)
9.88 in.
(251 mm)
7.102 in.
(180 mm)
14 lb
(6.4 kg)
235–890 43.559 in.
(1106 mm)
33.679 in.
(855 mm)
9.88 in.
(251 mm)
7.102 in.
(180 mm)
16 lb
(7.3 kg)
