Graco EcoQuip EQ200T - Repair; Repairing the Main Air Regulator

Repair
Repair Repair
Repair
Repairing Repairing
Repairing
the the
the
Main Main
Main
Air Air
Air
Regulator Regulator
Regulator
SeeCommonSpareParts,page47forrepairkits.
1.PerformPressureReliefProcedure,page8.
2.Makesurealloftheairpressureisrelievedinthe
unit.Ifnecessary,removetheair󰘰lterforaccess
totheairregulator.
3.Removethepistoncover.
NOTE: NOTE:
NOTE:
Thereisaspringinsidethiscover.
4.Removethediaphragmcoverforaccesstothe
diaphragmandtotheendofthepistonshaft.
EQ200
EQ400
5.Removethediaphragmandinspectforany
cracksortears.Replacethediaphragmif
necessary.
6.Carefullyremovethespringandpistonassembly,
thencleanoutanydebrisinthebodyofthe
regulator.
EQ200 EQ200
EQ200
Models Models
Models
only: only:
only:
Makesurethewiremeshis
freeofdebris.
7.Inspectthepistonanditssealforanyforeign
matterthatmayhavebeenthecauseforthe
pistontostayopen.
8.Inspectforanydamagetothepistonshaftwhere
itinteractswiththediaphragmcup.Replace
componentswithexcessivewear.
334666C
27
