Know Your Sprayer
8 3A8429B
Know Your Sprayer
GX21 Component Identification
A ON/OFF Switch
B Pressure Control Knob
C Gun Fluid Inlet Fitting
D Prime Valve
E Push Prime Button
F Tip Guard
G Reversible Spray Tip
H Airless Spray Gun
J Airless Hose
K Battery
L Gun Trigger Lock
M Drain Tube (with Diffuser)
N Fluid Intake (Suction) Tube
P
ProXChange
™
Pump (behind easy access door)
Q Gun Fluid Filter (inside handle)
R Fluid Outlet Fitting (airless hose connection)
S Grounding Wire with Clamp
T Inlet Valve Removal Tool
U Ground Adapter
V Easy Access Door with Cover
W Suction/Drain Tube Cup
X
InstaClean
™
Fluid Filter (inside fluid outlet)
Y Inlet Strainer
Z Pump Removal Tool
Model/Serial Tag (Not shown, located on bottom
of unit.)
