Graco G1 User Manual

Installation
14 332316E
Power CPC DC- 15 foot: Part No. 127783
CPC Connector Specifications
• One, 7-position, 1.5 mm socket connector AMP 967650-1
• Three, 16 - 14 gauge female pins AMP 962999-1
• One, 180-degree strain relief or one, 90-degree strain relief AMP 965576-1 (determined by cable exit for cable
configuration)
Installation Notes
• Crimp pins to wire and install in socket connector per manufacturer’s instructions.
• See Pin Layout shown in F
IG. 5 for proper location in the connector.
• Secure socket connector to the cable per the desired strain relief configuration.
Cable Specifications
• United States/Canada: 3 conductor 16 AWG UL62 and CSA 22.2 No. 49 listed SOOW cable with black, white,
green insulation
• Europe: 3 Class-5 conductor, 1.5 mm
2
Agency Listed H07RN-F cable with blue, brown, green/yellow insulation
• Japan/Taiwan: 3 conductor, 1/25 mm
2
Agency Listed 2 PNCT cable with black, white, red insulation
• SEA/India/Australia: 3 conductor, 1.5 mm
2
Agency Listed H07RN-F blue, brown, green/yellow insulation
• China: 3 conductor, 1.5 mm
2
Agency Listed YZW cable with blue, brown, green/yellow insulation
Pin and Related Wire Color (F
IG. 5, page 15)
UnitedStates/
Canada
Europe Japan/Taiwan
SEA/India/
Australia
China
1NotUsed NotUsed NotUsed NotUsed NotUsed NotUsed
2 ‐VDC Black Brown Black Brown Brown
3 +VDC White Blue White Blue Blue
4NotUsed NotUsed NotUsed NotUsed NotUsed NotUsed
5NotUsed NotUsed NotUsed NotUsed NotUsed NotUsed
6NotUsed NotUsed NotUsed NotUsed NotUsed NotUsed
7NotUsed Green Green/Yellow Red Green/Yellow Green/Yellow
Pin PinName
Colo r
