Installation
6 332316E
Installation
Grounding
Component Identification
Key:
A Reservoir
B Pump Element
C Pressure Relief Valve (Not included / required)
D Zerk Inlet Fill Fitting (1 included / grease models only)
E Power, DIN (if equipped)
F Power, CPC (if equipped)
G Low Level Output (if equipped)
H Model Number/ Serial Number
J Follower Plate (grease models only / not available on all
grease models)
K Vent Hole
L Fill cap (oil models only)
The equipment must be grounded. Grounding reduces the risk
of electric shock by providing an escape wire for the electrical
current in the event of malfunction or breakdown.
FIG. 1:
A
D
H
J
Oil Models
L
Grease Models
E
C
K
B
F
G
Grease Models with Follower Plate
