Graco G1 User Manual

Parts
332316E 27
Parts
Replacement Danger and Warning labels, tags and cards
are available at no cost.
‡ Also order Ref 31 and Ref 34.
† Also order Ref. 57 when ordering this part.
FN Part No. Description Qty.
1 BASE, molded 1
3 278142 BOTTOM, cover 1
4 115477 SCREW, bottom cover 9
13
124396
O-RING, 258 (green), included in Kit
571042, 571043, 571044, 571045,
571069, 571179
2
124510
O-RING, included in Kit 571069,
571179, 571182, 571183
1
14 PLATE, ricer 1
15 BEARING, ball 1
16
PADDLE, stirring, 2 liter models with-
out follower plate, included in Kit
571044
1
PADDLE, stirring, 4 and 8 liter mod-
els without follower plate, included in
Kit 571046
1
PADDLE, stirring, 2 liter models with
follower plate, included in Kit 571045
1
PADDLE, stirring, 4 liter models with
follower plate, included in Kit 571047
1
17 ELEMENT, pump 1
23‡ 278136 PADDLE, low level 1
27 123025 SCREW, M6 1
33 16A579 LABEL, safety 1
35
WIPER, stirring, models without fol-
lower plate, included in Kit 571044,
571046
1
WIPER, stirring, models with follower
plate, included in Kit 571045, 571047
1
37 123741
FITTING, zerk, grease models (not
included on oil models)
1
40a
RESERVOIR, 2 liter, grease,
included in Kit 571042, 571069
1
40b
RESERVOIR, 2 liter, oil, included in
Kit 571179
1
40a
RESERVOIR, 4 liter, grease,
included in Kit 571183
1
40b
RESERVOIR, 4 liter, oil, included in
Kit 571182
1
40a RESERVOIR, 8 liter grease 1
40b
RESERVOIR, 8 liter, oil, included in
Kit 571182
1
41
278139 SEAL, follower plate, 2 liter models 1
16F472 SEAL, follower plate, 4 liter models 2
16V763 SEAL, follower plate, 8 liter models 2
42 PLATE, follower, grease models 1
43 ROD, follower plate, grease models 1
44
SPRING, compression, grease mod-
els
1
45†
24D838 BAFFLE, low level, 2 liter models 1
24E246 BAFFLE, low level, 4 liter models 1
24F836 BAFFLE, low level, 8 liter models 1
57 117156 BEARING, sleeve 1
58 196548 LABEL, shock warning 1
60 16D984 WASHER, low level models 2
61
RESERVOIR, mid-section, 8 liter
models
1
62
ADAPTER, reservoir 4 and 8 liter
models
1
66 126417 NUT 1
67 24N806 FLOAT, oil models 1
FN Part No. Description Qty.
