No Controller Operation
22 332316E
Oil Pumps
When the oil level has reached a low warning level,
PINS 3 and 4 close, sending the signal to the controller
that the fluid has reached a low level.
To ensure that a low level condition has been met, the
low level trigger must be detected for 10 continuous sec-
onds.
See F
IG. 18 for an illustration of a typical Low Level Out-
put response to low oil level.
Typical Low Level Output Response with Low Level Fluid in Oil Models
FIG. 18
Contact
Position
