Graco GH 230 - DH230;GH230 Procontractor Series

Technical Data
334558D 65
DH230/GH
™
230 ProContractor Series
US Metric
Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar
Hydraulic reservoir capacity 1.25 gallons 4.75 liters
Maximum hydraulic pressure 1855 psi 12.8 MPa,128 bar
Engine
DH230 350 cc (6.7 HP)
GH230 200 cc (6.5 HP)
Maximum tip size 0.053
Maximum free-flow delivery 2.35 gpm 10.7 l/min
Hose connection 3/8 npsm (m)
Noise (dBa)
Maximum sound pressure
DH230
91 dBa
GH230
96 dBa
Maximum sound power
DH230
106 dBa
GH230
110 dBa
Inlet/Outlet Sizes
Fluid inlet size 1 5/16-12 UN-ZA
Fluid outlet size 3/8 npt (f)
Weight
DH230 230 lb. 104.2 kg
GH230 193 lb. 87.5 kg
Width 25.3 in. 64.3 cm
Length 44.8 in. 113.8 cm
Height (Hose Reel Up) 38.5 in. 97.8 cm
Pump Height (Hose Reel Sideways) 33.0 in. 83.8 cm
OEM Kit
Paint/Hydraulic pressure ratio 1.78:1
Max cycle rate 145 cpm
User Supplied Input
Max hydraulic pressure 1855 psi 12.8 MPa,128 bar
Hydraulic flow required in free-flow 6.60 gpm 25.0 l/min
Unit Output
Max fluid Pressure 3300 psi 22.8 MPa, 228 bar
Max flow 3.0 gpm 11.4 l/min
Weight 35 lb. 15.9 kg
Width 8.94 in. 227 mm
Depth 5.38 in. 137 mm
Height
28.80 in. 732 mm
