Technical Data
42 3A6400A
3900 Models
U.S. Metric
Engine
Honda GX120 Engine
Sprayer
Maximum Working Pressure 3300 psi 228 bar, 22.8 MPa
Maximum Tip Size:
1 Gun with 0.036 in. tip 1 Gun with 0.036 in. tip
2 Guns with 0.023 in. tip 2 Guns with 0.023 in. tip
3 Guns with 0.018 in. tip 3 Guns with 0.018 in. tip
Maximum Delivery Rating 1.25 gpm 4.73 lpm
Inlet Paint Strainer
8 mesh (2589 micron)
stainless steel screen, reusable
8 mesh (2589 micron)
stainless steel screen, reusable
Outlet Paint Filter
60 mesh (250 micron)
stainless steel screen, reusable
60 mesh (250 micron)
stainless steel screen, reusable
Pump Inlet Size 1-5/16-12 UN-2A 1-5/16-12 UN-2A
Fluid Outlet Size 1/4 npsm from fluid filter 1/4 npsm from fluid filter
Dimensions
Weight:
GMAX 3900 Standard 106 lb 48.2 kg
GMAX 3900 Lo-Boy 123 lb 55.9 kg
GMAX 3900 ProContractor 133 lb 60.5 kg
Height:
GMAX 3900 Standard 40.8 in. 103.6 cm
GMAX 3900 Lo-Boy 26.4 in. 67.1 cm
GMAX 3900 ProContractor 38.3 in. 97.3 cm
Length:
GMAX 3900 Standard 38.3 in. 97.3 cm
GMAX 3900 Lo-Boy 46.9 in. 119.1 cm
GMAX 3900 ProContractor 32.3 in. 82.0 cm
Width:
GMAX 3900 Standard 22.3 in. 56.6 cm
GMAX 3900 Lo-Boy 24.4 in. 62.0 cm
GMAX 3900 ProContractor 22.3 in. 56.6 cm
Wetted parts
zinc- and nickel-plated carbon steel, PTFE, nylon, polyurethane, UHMW,
fluoroelastomer, acetal, leather, aluminum, tungsten carbide,
stainless steel, chrome plating
Noise Level:
Sound Power 105 dBa per ISO 3744 105 dBa per ISO 3744
Sound Pressure 96 dBa measured at 3.1 ft 96 dBa measured at 1 m
