Know Your Sprayer
10 3A3212C
DI Stand Models
A Prime / Spray Valve
B PushPrime Button
C Pressure Control Knob
D ON/OFF Switch
E Suction Tube
F Drain Tube (with diffuser)
G Airless Spray Gun
H Reversible Spray Tip
J Tip Guard
K Gun Trigger Lock
L Gun Fluid Inlet Fitting
M Gun Fluid Filter (inside handle)
N ProXChange™ Pump (behind Easy
Access Door)
P Pump Fluid Outlet Fitting (airless
hose connection)
Q Airless Hose
R InstaClean™ Fluid Filter (inside fluid
outlet)
T Inlet Strainer
U Power Cord
V Easy Access Door with Cover
W Suction / Drain Tube Cup
X Pump Removal Tool
Z Inlet Valve Removal Tool
Model/Serial Tag (Not shown, located
on bottom of unit.)
See Quick Reference, page 32 for more
information.
