Pressure Relief Procedure
8 3A4980B
Pressure Relief Procedure
Follow the Pressure Relief
Procedure whenever you see this
symbol.
1. Turn the HVLP sprayer ON/OFF switch
to OFF position.
2. Unplug power cord to disconnect power
from the HVLP sprayer.
3. Disconnect spray gun from air hose.
NOTE: If using a remote cup, refer to manual
provided with cup. If using with a Graco
FinishPro HVLP ProComp sprayer,
reference sprayer manual.
4. If using a FlexLiner System:
Disconnect tubing from gun to relieve
pressure in the cup.
5. If using a metal siphon cup:
Unlatch cup cover, loosen or remove cup
from cover to relieve pressure.
The spray gun cup is pressurized. To
reduce the risk of splashing from
pressurized fluid, always follow the
Pressure Relief Procedure before
removing cup.
ti30757a
